Model

TD-2004NS-HL

System

Embedded Linux

Video

Analog Video Input

BNC × 4

BNC Interface

1.0Vp-p; 75Ω

TVI/AHD/CVI

1080P/1080P Lite/720P/720P Lite/WD1

IP Video Input

2CH

Max Resolution

Up to 2MP@30fps

Total Input

6CH

Output

HDMI

1: 1920×1080/1280×1024/1024×768

VGA

1: 1920×1080/1280×1024/1024×768

Compression

H.264/H.265

Multi-screen Display

1/4/6/9

Audio

Input

RCA × 1

Output

RCA × 1 (linear, 600Ω)

Two-way audio

Take up channel one audio input

Compression

G.711(U/A)

Record

Resolution

1080P Lite/720P/720P Lite/WD1

Frame Rate

Analog Channel: 4CH DVR: 1080P Lite/720P/WD1: 25fps (PAL)/30fps (NTSC) 8CH DVR: 1080P Lite/720P/WD1: 25fps (PAL)/30fps (NTSC) (only CH 1 supports) 1080P Lite/720P/WD1: 12fps (PAL)/15fps (NTSC) (other channels support) 720P Lite: 25fps(PAL)/30fps (NTSC) IP Channel: 25fps(PAL)/30fps (NTSC)

Bit Rate

32Kbps ~ 4Mbps

Playback

Playback

4CH

Search

Method

Time slice/time/event/tag search

Smart Search

Highlight colors to display camera record in a certain period of time, different colors refer to different record events

Function

Play, pause, FF, FB, digital zoom, etc.

Alarm

Mode

Manual, motion, exception, smart event

Input

No

Output

No

Network

Interface

RJ45 100Mbps × 1

Protocol

TCP/IP, PPPoE, DHCP, DNS, DDNS, UPnP, HTTP, HTTPs, NTP, SMTP

Incoming Bandwidth

10Mbps

Outgoing Bandwidth

30Mbps

Client Connection

Max. 5 users access

Mobile Device

OS

iOS, Android

Storage

HDD

SATA × 1, up to 8TB

Backup

Local Backup

U disk, USB mobile HDD

Network Backup

Yes

Ports

RS 485

No

USB

USB 2.0 × 2

Remote Controller

No

Others

Power Supply

DC12V/1.5A

Consumption

≤ 5W (without HDD)

Dimensions (mm)

255 × 222 × 42 (W × D × H)

Working Environment

Temperature

-10~50°C

Humidity

10%~90%

Certificate

CE, FCC

CE, FCC

Environment Protection

Directive

EU RoHS, WEEE, REACH
